74AUP1G07.pdf? Wide Supply Voltage Range: 0.8V to 3.6V
? Inputs Accept Voltages Higher than the Supply
Voltage
? 4mA Output Current
? Low Quiescent Current: ICC = 0.1μA (TYP)
? Low Dynamic Power Dissipation:
CPD = 2.5pF at VCC = 3.3V (TYP)
? Input with Schmitt-Trigger
? Support Partial Power-Down Mode
? -40℃ to +125℃ Operating Temperature Range
? Available in Green SC70-5, SOT-23-5 and
UTDFN-1.45×1-6AL Packages
? Available in the Ultra Small 0.64 mm2 Package
? (DPW) with 0.5-mm Pitch
? Low Static-Power Consumption
? (ICC = 0.9 ?A Maximum)
? Low Dynamic-Power Consumption
? (Cpd = 1 pF Typical at 3.3 V)
? Low Input Capacitance (Ci = 1.5 pF Typical)
? Low Noise – Overshoot and
Undershoot<10% of VCC
? Ioff Supports Live Insertion, Partial-
Power-Down Mode, and Back-Drive Protection
? Input Hysteresis Allows Slow Input Transition and
Better Switching Noise Immunity at the Input
(Vhys = 250 mV Typ at 3.3 V)
? Wide Operating VCC Range of 0.8 V to 3.6 V
? Optimized for 3.3-V Operation
? 3.6-V I/O Tolerant to Support Mixed-Mode Signal Operation
? tpd = 3.3 ns Maximum at 3.3 V
? Suitable for Point-to-Point Applications
? Latch-Up Performance Exceeds 100 mA
Per JESD 78, Class II
? ESD Performance Tested Per JESD 22
2000-V Human-Body Model(A114-B, Class II)
1000-V Charged-Device Model (C101)
