74AVC8T245Q.pdf? AEC-Q100 Qualified for Automotive Applications
Device Temperature Grade 1
TA = -40℃ to +125℃
? VCCA Supply Voltage Range: 0.8V to 3.6V
? VCCB Supply Voltage Range: 0.8V to 3.6V
? Inputs Accept Voltages up to 3.6V
? +12mA/-12mA Output Current
? Data Rates:
380Mbps (≥ 1.8V to 3.3V Translation)
260Mbps (≥ 1.1V to 3.3V Translation)
260Mbps (≥ 1.1V to 2.5V Translation)
210Mbps (≥ 1.1V to 1.8V Translation)
150Mbps (≥ 1.1V to 1.5V Translation)
100Mbps (≥ 1.1V to 1.2V Translation)
? Outputs in High-Impedance State when VCCA or
VCCB = 0V
? -40℃ to +125℃ Operating Temperature Range
? Available in a Green TQFN-3.5×5.5-24AL Package
? Automotive product qualification in accordance
? Wide supply voltage range:
VCC(A): 0.8V to 3.6V; VCC(B): 0.8V to 3.6V
? DHVQFN package with Side-Wettable Flanks enabling
Automatic Optical Inspection (AOI) of solder joints
