ACP2825.pdf? Input Voltage Range: 2.5V to 6V
? Output Current: 1.2A
? Adjustable Output with 0.6V Reference Voltage
? Automatic PFM Mode at Light Load
? Low Dropout 100% Duty Operation
? 1.5MHz Programmable Frequency
? Maximum 65μA Quiescent Current
? Internal Soft Start Function
? Excellent Line and Load Transient Response
? Short Circuit Protection
? Input Over Voltage Protection
? Under Voltage Lockout Protection
? Up to 95% Efficiency
? Low RDS(ON) Switches 150 mΩ / 100 mΩ
? 2.5-V to 5.5-V Input Voltage Range
? Adjustable Output Voltage from 0.6 V to VIN
? Power Save Mode for Light Load Efficiency
? 100% Duty Cycle for Lowest Dropout
? 35-μA Operating Quiescent Current
? 1.5-MHz Switching Frequency
? Power Good Output
? Over Current Protection
? Internal Soft Startup
? Thermal Shutdown Protection
